Weichai Power

Stable and efficient power solutions

Sufficient supply and project compliance

Brand Introduction Technical Parameters Equipment Details Equipment Details

The power range of Weichai generator sets is 20 KW - 3000KW. These gensets utilize engines independently developed and produced by the Weichai Group, paired with renowned brand generators and controllers. The generator product series includes the Yangchai series, Deutz WP4/WP6 series, WP10 series, WP12 series, WP13 series, 160 series, 170 series, and Baudouin series, among others. By integrating these generators with well-known domestic and international brand generators produced using introduced technologies, Weichai manufactures technologically leading generator sets in China.

Technical Parameters

Genset Model	Rated Power （KW/KVA）	Rated Current (A)	Engine model	Engine Power (KW)	Cyinder No.-Bore*Stroke (mm)	Overall Dimensions (LWH)(mm)	Net Weight （Kg）
Weichai (China II) serie
HC-20WII	20	36	WP2.3D25E200	23	4/L-89*92	18009001270	755
HC-24WII	24	43	WP2.3D33E200	30	4/L-89*92	18009001300	800
HC-30WII	30	54	WP2.3D40E200	36	4/L-89*92	18009001300	800
HC-40WII	40	72	WP2.3D48E200	44	4/L-89*92	18009001300	800
HC-50WII	50	90	WP4.1D66E200	60	4/L-105*118	19509201340	1100
HC-64WII	64	115	WP4.1D80E200	72	4/L-105*118	18507001200	1000
HC-80WII	80	144	WP4.1D100E200	91	4/L-105*118	22008001340	1250
HC-90WII	90	162	WP4.1D113E200	96	4/L-105*118	22008001350	1250
HC-100WII	100	180	WP6D132E200	120	6/L-105*130	24708301450	1350
HC-120WII	120	216	WP6D152E200	138	6/L-105*130	24709301450	1400
HC-150WII	150（备）	270	WP6D167E200	152	6/L-105*130	25509501300	1430
HC-150WII	150	270	WP10D200E200	182	6/L-126*130	275010501400	1880
HC-180WII	180	324	WP10D238E200	216	6/L-126*130	275010501500	2100
HC-200WII	200	360	WP10D264E200	240	6/L-126*130	290011001550	2200
HC-250WII	250	450	WP10D320E200	291	6/L-126*130	300010501550	2700
HC-300WII	300	540	WP12D353E200	288	6/L-126*130	295011001680	2500
HC-320WII	320	576	WP13D385E200	350	6/L-127*165	300010001850	2500
HC-350WII	350（备）	630	WP13D405E200	365	6/L-127*165	300010001850	2600
HC-350WII	350	630	WP13D440E310	392	6/L-127*165	298012401855	2650
HC-400WII	400	720	WP13D490E310	450	6/L-127*165	298012401855	2650
HC-450WII	450	810	6M33D572E200	520	6/L-150*185	360015001850	5000
HC-500WII	500	900	6M33D633E200	572	6/L-150*185	360015001900	5500
HC-600WII	600（备）	1080	6M33D670E200	610	6/L-150*185	365015001900	6000
HC-600WII	600	1080	6M33D725E200	675	6/L-150*185	365015001900	6000
HC-640WII	640	1152	12M26D792E200	720	12/V-150*150	434020402360	7800
HC-720WII	720	1296	12M26D902E200	820	12/V-150*150	450018502200	8000
HC-640WII	640	1152	8M33D800E200	730	8/V-150*185	403018712131	6900
HC-720WII	720	1296	8M33D890E200	815	8/V-150*185	403018712131	6900
HC-800WII	800	1440	12M26D968E200	880	12/V-150*150	434020402360	8400
HC-900WII	900	1620	12M33D1108E200	1007	12/V-150*185	480020002350	9200
HC-1000WII	1000	1800	12M33D1210E200	1100	12/V-150*185	480020002350	9300
HC-1100WII	1100	1980	12M33D1320E200	1200	12/V-150*185	480020502450	9800
Weichai (China III) series
HC-15WIII	15	27	WP3.2D20E310	18	4/L-98*105	16008001200	780
HC-24WIII	24	43	WP3.2D28E310	25	4/L-98*105	17438461253	875
HC-30WIII	30	54	WP3.2D36E310	33	4/L-98*105	17608001200	950
HC-30WIII	30	54	WP3.2D44E310	36.8	4/L-98*105	17608001200	950
HC-50WIII	50	90	WP4.1D66E310	60	4/L-105*118	18008501300	1020
HC-64WIII	64	115	WP4.1D84E310	74.5	4/L-105*118	19009001350	1300
HC-80WIII	80	144	WP4.1D105E310	96	4/L-105*118	20009001400	1400
HC-90WIII	90	162	WP4.6ND120E310	110	4/L-108*125	20009001400	1400
HC-100WIII	100	180	WP4.6ND138E310	125	4/L-108*125	23509001550	1450
HC-120WIII	120	216	WP4.6ND148E310A	135	4/L-108*125	24009301550	1480
HC-150WIII	150	270	WP7D185E310	168	6/L-108*136	25009001600	1800
HC-180WIII	180	324	WP7D240E310	218	6/L-108*136	25009501650	1800
HC-200WIII	200	360	WP7D264E310	235	6/L-108*136	25009501700	2000
HC-250WIII	250	450	WP10D320E350	290	6/L-126*130	300010501750	2800
HC-300WIII	300	540	WP13D385E310	350	6/L-127*165	300011001750	3200
HC-350WIII	350	630	WP13D440E310	392	6/L-127*165	300011001750	3200
HC-400WIII	400	720	WP13D490E310	450	6/L-127*165	300011001750	3200
HC-520WIII	520	936	6M33D633E310	575	6/L-150*185	380016501900	5500
HC-600WIII	600	1080	6M33D725E310	675	6/L-150*185	365015001900	6000
HC-640WIII	640	1152	8M33D800E310	730	8/V-150*185	403018712131	6900
HC-720WIII	720	1296	8M33D895E310	815	8/V-150*185	403018712131	6900
HC-800WIII	800	1440	8M33D975E310	890	8/V-150*185	403018712131	6900
HC-800WIII	800	1440	12M33D968E310	872	12/V-150*185	450018502200	7500
HC-900WIII	900	1620	12M33D1108E310	1007	12/V-150*185	470022002400	7500
HC-1000WIII	1000	1800	12M33D1240E310	1130	12/V-150*185	450018502200	7300
HC-1100WIII	1100	1980	12M33D1320E310	1200	12/V-150*185	530020002300	7800
HC-1200WIII	1200	2160	12M33D1500E310	1350	12/V-150*185	530020002300	8000
HC-1250WIII	1250	2250	16M33D1530E310	1390	16/V-150*185	540022002500	9000
HC-1400WIII	1400	2520	16M33D1680E310	1530	16/V-150*185	555022502600	9200
HC-1500WIII	1500	2700	16M33D1800E310	680	16/V-150*185	555022502600	9500
HC-1600WIII	1600	2880	16M33D1980E310	1800	16/V-150*185	560023002600	10000
HC-1600WIII	1600	2880	20M33D2020E310	1850	20/V-150*185	565024502950	10500
HC-1800WIII	1800	3240	20M33D2210E310	2010	20/V-150*185	580024502950	12750
HC-1800WIII	1800	3240	12M55D2210E310	1985	12/V-180*215	680025002600	15500
HC-2000WIII	2000	3600	12M55D2450E310	2200	12/V-180*215	680025002600	15500
HC-2200WIII	2200	3960	12M55D2700E310	2420	12/V-180*215	680025002600	15500
HC-2400WIII	2400	4320	16M55D2570E310	2500	16/V-180*215	800025002700	18500
HC-2400WIII	2400	4320	16M55D2900E310	2646	16/V-180*215	800025002700	19000
HC-2600WIII	2600	4680	16M55D3300E310	2900	16/V-180*215	820025502700	19000
HC-3000WIII	3000	5400	16M55D3600E310	3300	16/V-180*215	823026002700	20000
